Marantz Cinema50

Marantz Cinema50

Premium 9.4 channel 110-watt-per-channel amplification, Dolby Atmos, DTS:X and Auro-3D, 8K Ultra HD, and HEOS® Built-in streaming. CINEMA 50 is a powerful AV amplifier for very high-performance home theatres

Specifications

• Artisanal Design
• 9.4 Channels
• 110 Watts per Channel
• 6 HDMI Inputs plus eARC
• 8K & Dolby Atmos
• HEOS Built-in

Key Features

Power Amplifier

• Number of Powered Channels: 9
• Power Output (8 Ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive): 110W
• Power Output (6 Ohm, 1 kHz, 0.7% 2ch Drive): 150W
• Power Output (6 Ohm, 1 kHz, 10% 1ch Drive): 220W
• 70% Guarantee: Yes
• Discrete Power Amplifier: Yes
• Amplifier Topology: Class A/B
• Current Feedback Topology: Yes
• Bi-Amp Drive: Assignable


Multichannel Surround Technologies

• DTS Formats: DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
• Dolby Formats: Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualisation, Dolby Atmos Music, Dolby Surround
• Other Formats: IMAX Enhanced, Auro-3D, 360 Reality Audio, MPEG-H, Multichannel Stereo
• Max Number of Processing (Preamp) Channels: 11.4


Inputs Outputs

• Composite In / Out: 0 / 0
• Component In / Out: 0 / 0
• HDMI In / Out: 6 / 3
• Multi-Room Video Out via HDMI: Yes
• Analogue In / Fixed Level Out: 5 in / 0 out
• Phono (MM) In: Yes
• Digital In (Optical / Coaxial): 2 / 2
• Multi-Room Out (Analogue / Digital): 1 / 0
• Multichannel Preamp Out: 11.4
• Subwoofer Out: 4 (independent)
• 7.1 Multichannel Input: No
• Number of Speaker Terminals: 11
• Speaker A / B: Assignable
• Multi-Room Speaker Terminal: Assignable
• USB-A: Yes
• USB Audio / Made for iPod / Made for iPhone: Yes / No / No
• AM/FM Tuner: No
• USB Audio: Yes


HDMI

• Total HDMI Inputs / No. Supporting 8K: 6 / 6
• HDCP 2.3 Support: Yes
• HDMI Outputs (Main / Zone): 2 / 1
• Analogue to HDMI Video Conversion: No
• HDMI Upscaling: 1080P / 4K to 8K
• Max Resolution @ Framerate: 8K/60Hz, 4K/120Hz
• Audio Return Channel: ARC, eARC
• Video Dynamic Range: HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
• ALLM (Auto Low Latency Mode) Pass-through for Gaming: Yes
• Variable Refresh Rate / Quick Frame Transport: Yes / Yes
• HDMI Pass-Through in Standby Mode: Yes
• CEC: Yes
• DSD Audio Over HDMI: Yes
• Auto LipSync: Yes


Performance Technologies

• Copper-Plated Chassis: No
• Toroidal Power Supply Transformer: No
• Hyper Dynamic Amplifier Modules (HDAM): Yes
• Pure Direct Mode: Yes
• Gold-Plated RCA Terminals: Yes
• Clock Jitter Reducer: Yes


Acoustic Room Correction

• Audyssey MultEQ XT32: Yes
• Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
• Audyssey LFC: Yes
• Dirac Live Upgradability: Yes
• Variable Crossover: Yes
• Optimised Bass Redirection: Yes
• Bass Sync: Yes


Music File Support

• Lossy Formats: MP3 / WMA / AAC
• Lossless Formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
• DSD Audio: 2.8 MHz / 5.6 MHz
• Gapless Playback: FLAC, WAV, ALAC, DSD
• Compressed Audio Enhancer (MDAX2): Yes
• Network Audio Sharing: Yes


Streaming Services

• HEOS Multi-Room & Streaming: Yes
• AirPlay Audio Streaming: AirPlay 2
• Internet Radio: TuneIn
• Spotify: Spotify Connect
• Pandora: No
• SiriusXM: Yes
• Other Streaming Services: Amazon Music HD, Amazon Music, TIDAL, Deezer, iHeart Radio, Napster, SoundCloud, Mood Mix
• Roon Tested: Yes


Network Connectivity

• Ethernet Ports: Yes
• Wi-Fi: Yes
• Bluetooth: Yes
• Bluetooth Re-Transmit for Bluetooth Headphones: Yes


Smart Home Integration and Control

• Voice Assistant Compatibility: Alexa, Google Voice Assistant, Apple HomePod
• App for Smart Phones & Tablets (iOS & Android): Marantz AVR Remote App, HEOS
• HEOS Multi-Room Integrated: Yes
• HEOS Link Compatibility (IR / IP): Yes / Yes

• Multi-Room Zones: 2
• Zone Audio Source (HDMI / Optical, Coaxial / Network, USB / Analogue): 2 Ch / 2 Ch / Yes / Yes
• Zone Audio Output (Speaker / Pre-Out): Yes / Yes
• Zone HDMI Output from HDMI Source: Yes
• IP Control / RS232 Control / Web Control / App Control: Yes
• IR Flasher In: Yes
• Marantz Remote Bus: Yes
• DC Trigger Output: 1
• HDMI Diagnostics: Yes

General

• Available Colours: Black
• Metal Front Panel: Yes
• System Remote Control: RC049SR
• Power Consumption (W): 680
• Power Consumption (No-Sound, ECO On/Off) (W): 60 / 100
• Standby Consumption (W): 0.2
• CEC Standby Consumption (W): 0.5
• Network Standby Consumption (W): Less than 2.0

• Maximum Dimensions
  Antenna:Horizontal:(W x D x H) in mm
  Antenna:Vertical :(W x D x H) in mm
  W/o Antenna:(W x D x H) in mm442 x 404 x 165
  (442 x 404 x 235)
  【 442 x 392 x 165 】
• Weight in kg: 13.5
• What's in the box: Main unit, remote control, batteries, wire labels, quick start guide, Audyssey microphone, microphone stand, 2 External Detachable Antenna, AC cord

Others

• Front Display: Porthole OLED
• GUI Languages: 3
• Setup Assistant: Yes
• Smart Select on Remote: Yes
• Firmware Update (by Network / USB): Yes / Yes
• ECO Mode: Yes
• Auto Power Off: Yes
• Sleep Timer: Yes
